ANDREW / COMMSCOPE APT-DFDM-DB Arrestor Plus® Dual Band

ANDREW / COMMSCOPE APT-DFDM-DB Arrestor Plus® Dual Band Quarterwave Surg

ANDREW / COMMSCOPE APT-DFDM-DB Arrestor Plus® Dual Band Quarterwave Surge Arrestor (T-shaped) 806?960 MHz and 1700?2170 MHz with interface types DIN Female and DIN Male

ANDREW / COMMSCOPE
APTDFDMDB
$1,456.29
IVA incluido
Solicitar Info

MensajeWhatsapp Solicitar Información por Whatsapp
MensajeWhatsapp Solicitar Información por Correo
Llamar Llamar por Teléfono Tel. 55 1209 0327

APTDFDMDB Arrestor Plus® Dual Band Quarterwave Surge Arrestor (T-shaped), 806?960 MHz and 1700?2170 MHz, with interface types DIN Female and DIN Male APT-DFDM-DB

General Specifications
  • Device Type: dc Block
  • Interface: 7-16 DIN Female
  • Interface 2: 7-16 DIN Male
  • Harmonized System (HS) Code: 854420 (Coaxial cable and other coaxial electric conductors)
Electrical Specifications
  • Operating Frequency Band:
    - 1710 – 2000 MHz
    - 2000 – 2170 MHz
    - 806 – 960 MHz
    - 960 – 1710 MHz
  • 3rd Order IMD   -117.0 dBm   |   -160.0 dBc
  • 3rd Order IMD Test Method   Two +43 dBm carriers
  • Average Power   3000.0 W @ 900 MHz
Physical Characeristics
  • Dimensions (Height x Length x Width);
    (74.23 mm x 76.97 mm x 36.07 mm) |   (2.92 in x  3.03 in x 1.42 in)
  • Weight   434.99 g   |   0.96 lb
  • Attenuation Ambient Temperature   20 °C   |   68 °F
  • Average Power Ambient Temperature   40 °C   |   104 °F

APT-DFDM-DB Arrestor Plus® Dual Band Quarterwave Surge Arrestor (T-shaped), 806?960 MHz and 1700?2170 MHz, with interface types DIN Female and DIN Male APTDFDMDB
